PASS THRU - HEPA FILTERED
***100% Recirculated Airflow****
- Construction of double wall 20 Ga, type 304 SS, # 4 polish
- Also available as 316
- ID 18"W X 18"H X 18"d
- OD 26"W X 34"H X 21"d
- Two (2) SS Doors
- Tempered safely glass view window
- Latching compression handles,
- Top mounted recirculating HEPA filtered ceiling with gasket seal replaceable 99.99% HEPA
- Electrical interlock 120-1-60 power required
- ETL Listed complies with "UL 507"

PASS THRU - HEPA FILTERED
****100% Recirculated Airflow****
- Construction of double wall type 304 stainless steel
- Also available as 316
- ID 24"W X 24"H X 24"D
- OD 32"W X 43"H X 26"D
- Two (2) SS Doors with 1/4" tempered safety glass viewing windows, latching compression handles
- Electric interlock 120-1-60 voltage required
- Top mounted 100% recirculating HEPA filtered ceiling with gel seal replaceable 99.99% HEPA, motorized impeller, 115V, 100W motor, 240 CFM.
- Perforated work deck with air return below.
- Hand off auto switch
- Adjustable 5 minute timer for fan
- 3/4" NPT aerosol injection port
- External control panel with pressure gauge
- Mounting trim to be 1 1/2" X 1 1/2" X 16 GA 304 SS angle

HEPA Filtered Pass Thru
****100% Recirculated Airflow****
- Construction of double wall type 304 stainless steel
- ID 24"W X 24"H X 28"D
- OD 36"W X 56"H X 30"D
- Two (2) SS doors with 1/4" tempered safety glass viewing windows, latching compression handles
- Electric interlock 120-1-60 voltage required
- Top mounted 100% recirculating HEPA filtered ceiling with gel seal replaceable 99.99% HEPA, motorized impeller, 115V, 100W motor, 240 CFM.
- Perforated work deck with air return below.
- Hand off auto switch
- Adjustable 5 minute timer for fan
- 3/4" NPT aerosol injection port
- External control panel with pressure gauge
- Mounting trim to be 1 1/2" X 1 1/2" X 16 GA 304 SS angle
